Louis Metals stands out as a premier stainless steel supplier and manufacturer based in Houston, USA. We take pride in offering top-notch Stainless Steel 904L Bars and Rods, renowned for their exceptional corrosion resistance in harsh environments. This high-alloy austenitic stainless steel is designed to withstand strong acids, chlorides, and seawater, making it perfect for critical industrial applications. At Louis Metals, our 904L bars and rods are meticulously engineered to meet international quality standards, ensuring remarkable durability, weldability, and performance. We provide a diverse range of sizes and custom specifications tailored to the needs of the chemical, marine, pharmaceutical, and oil & gas industries.
Stainless Steel 904L Bars and Rods are made up of 19–23% chromium, 23–28% nickel, 4–5% molybdenum, 1–2% copper, and a minimal carbon content (max 0.02%). This distinctive alloy composition grants outstanding resistance to sulfuric, phosphoric, and acetic acids, as well as to pitting and crevice corrosion in chloride-rich settings. The mechanical properties include a tensile strength ranging from 490–710 MPa, a yield strength of about 220 MPa, and impressive elongation and toughness. In its annealed state, 904L is non-magnetic and maintains excellent formability and weldability, even in corrosive and high-temperature industrial conditions.
| Grade | SS 904L – UNS N08904 |
|---|---|
| Specification | ASTM A276 UNS N08904, WS 1.4539, AFNOR Z2CNDU 25-20 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 904Lmm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel 904L Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Stainless Steel 904L Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Our stockyad location for fast delivery across India | Coimbatore, Bhubaneswar, Ahmedabad, Bengaluru, Thiruvananthapuram, Agra, Chennai, Noida, Mumbai, Shivamogga, Dhanbad, Hyderabad, Tiruchirappalli, Tirunelveli, Pune, Pimpri-Chinchwad, Navi Mumbai |
| Our Stainless Steel 904L Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L Bars and Rods find extensive use in highly corrosive environments where standard stainless steels fall short. They are commonly utilized in heat exchangers, condensers, and piping systems within chemical processing, oil refining, and marine applications. Additionally, 904L is perfect for crafting components in the pharmaceutical and food industries, where resistance to contamination is vital. It excels in sulfuric acid and chloride-rich atmospheres, making it suitable for offshore structures, desalination plants, and paper & pulp equipment. At Louis Metals, we offer a wide selection of 904L rods and bars to meet your specific needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
