Louis Metals is a well-established firm in the supply and production of Titanium Rectangular Bars in Houston, USA. Our rectangular bars are precision-engineered to meet various industrial applications, providing excellent durability, formability, and corrosion resistance. Produced to precise dimensional tolerances, these bars comply with national and international quality specifications. We cater to customers from aerospace, chemical, marine, and medical industries, providing flexible order quantities and speedy delivery. At Louis Metals, our dedication to quality, state-of-the-art manufacturing methods, and technical proficiency guarantees our Titanium Rectangular Bars offer superior value and enduring performance in the most adverse conditions.
Louis Metals’ Titanium Rectangular Bars are manufactured in Grades 2, 5, and 12. The bars offer lightweight characteristics with notable mechanical strength and corrosion resistance. Grade 2 has good weldability and formability, whereas Grade 5 (Ti-6Al-4V) has high tensile strength and toughness. The usual tensile strength is between 350 MPa and 950 MPa. Rectangular structure offers even strength over flat surfaces and edges, and thus they are suitable for structural uses. They are also mechanically stable at high temperatures and have high resistance to oxidation and corrosive substances.
| Standard | ASTM B348/ASME SB348, ASTMF67, ASTM F136, ISO-5832-2(3), AMS4928, MIL-T-9047G, JIS etc |
| Grade | TA1-TA4, TA7-TA10, TA15-TA18, GR1-GR5, GR6,GR7, GR9, GR11, GR12, TI-6AL-4V, TI-6AL-4VELI,GR23 |
| Diameter | 5-350mm |
| Length | Max6000mm |
| Technique | Forging ,Machining |
| Surface | acid surface or polishing, sand blasted surface |
| Shape | Rectangular |
| Application | Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc. |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Yes, Titanium Rectangular Bars are machinable, though they require specific tools and techniques due to their strength and hardness compared to other metals.
Yes, Titanium Rectangular Bars are highly resistant to corrosion, particularly in seawater, acids, and other harsh environments, making them ideal for marine and chemical applications.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@www.louismetals.us
Titanium Rectangular Bars find extensive applications in structural and support elements because of their flat shape and strength. They are applied in the aerospace sector as brackets, structural supports, and fasteners. In offshore and marine engineering, rectangular bars are corrosion resistant to saltwater and find application in hull supports and underwater frames. Rectangular bars are also applied in the chemical industry in equipment that is exposed to aggressive environments, like reactors and mixers. Architectural and defense industries appreciate them for their clean look and long-lasting durability. Their durability, resistance to corrosion, and machinability render them a diversified product for precision fabrication.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
