Luois Metals stands out as a trusted manufacturer and supplier of MP35N Bars and Rods, proudly catering to clients in Houston, the USA, and beyond. With a reputation for precision engineering and high-performance alloys, we deliver MP35N products that adhere to the highest industrial standards. This multiphase nickel-cobalt-based alloy is renowned for its exceptional strength, corrosion resistance, and biocompatibility. Our bars and rods are crafted under rigorous quality control and come in a variety of diameters, tempers, and lengths. These robust alloys find their place in industries like aerospace, medical, marine, and chemical processing. At Luois Metals, we prioritize timely delivery and dependable performance for all your critical applications.
The composition of MP35N Bars and Rods includes around 35% cobalt, 35% nickel, 20% chromium, and 10% molybdenum. This distinctive alloy blend provides remarkable mechanical properties, such as ultra-high tensile strength (reaching up to 300 ksi), excellent fatigue resistance, and impressive corrosion resistance, even in challenging environments like seawater, acidic media, and high-pressure systems. MP35N can be work-hardened and age-hardened to boost its strength even further. It maintains stability at elevated temperatures and resists hydrogen embrittlement, making it a top choice for demanding and corrosive settings. Plus, this alloy is non-magnetic and keeps its mechanical properties intact even after extended use.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
Yes, MP35N bars can be recycled after use. As a high-performance alloy, it can be melted down and reused to produce new components without significant loss of quality.
MP35N rods are sized based on their diameter and length, typically ranging from 1/16" to 6" diameter and custom lengths, depending on application requirements and manufacturing specifications.
MP35N rods are available in various sizes, typically ranging from 1/8" to 8" in diameter. Common finishes include cold drawn, hot rolled, and annealed for enhanced machinability and surface quality.
MP35N Bars and Rods are essential in critical applications where high strength, corrosion resistance, and fatigue life are non-negotiable. In the aerospace sector, they’re utilized in fasteners, springs, and structural components. In the realm of medical technology, MP35N is a go-to for surgical instruments, orthopedic implants, and cardiovascular devices, thanks to its biocompatibility. The oil and gas industry also relies on this versatile alloy for various applications, ensuring safety and performance in challenging conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
