Louis Metals is a leading manufacturer and supplier of top-notch stainless steel products, proudly based in Houston, USA. Among our wide array of offerings, the Stainless Steel 431 Hex Bar truly shines with its impressive strength, durability, and resistance to corrosion. Thanks to its martensitic structure and outstanding mechanical properties, SS 431 hex bars are perfect for tough industrial applications. At Louis Metals, we take pride in ensuring that each bar adheres to strict quality standards and specifications. Our state-of-the-art manufacturing capabilities and dedication to precision have established us as a reliable name in stainless steel supply throughout the U.S., serving industries like engineering, automotive, aerospace, and marine.
The Stainless Steel 431 Hex Bar is a martensitic stainless steel alloy featuring a well-balanced chemical composition that includes about 15.0–17.0% chromium, 1.25–2.50% nickel, and a maximum of 0.20% carbon. It boasts a high tensile strength of around 850 MPa, a yield strength close to 620 MPa, and remarkable toughness after heat treatment. With a Brinell hardness reaching up to 260 HB, SS 431 hex bars provide both strength and corrosion resistance. This impressive mechanical profile makes them ideal for components that demand high strength, toughness, and moderate corrosion resistance.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| ement | C | Cr | Mn | Ni | P | S | Si |
| SS 431 | 0.20 | 17.00-15.00 | 1.00 | 2.50-1.25 | 0.040- | 0.030 | 1.00 |
| Element | Density | Electrical Resistivity | Modulus of Elasticity |
| SS 431 | 0.2800 lb/inch³ | 70° Ohms (circ mil./ft.) | 29.0 X 10^3 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 431 Hex Bars find extensive use across various industries, thanks to their strength, corrosion resistance, and hardness. They are commonly used in the production of bolts, valves, pump shafts, marine fittings, and aircraft components. In the oil and gas industry, these bars are preferred for downhole tools and drilling equipment. The aerospace and defense sectors utilize 431 hex bars in structural and mechanical parts where strength and wear resistance are essential. Their reliable performance in mildly corrosive environments also makes them a great choice for food processing and chemical industries. At Louis Metals, we guarantee consistent quality for all industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
