Louis Metals is a global leader in the manufacturing and supply of high-grade Stainless Steel 431 Square Bars and Rods in Houston, USA. Louis Metals, focusing on quality, accuracy, and customer satisfaction, provides corrosion-resistant and high-performance stainless steel material to meet the stringent requirements of different industries. Louis Metals’ stainless steel rods and bars are manufactured with advanced technology and high-quality raw material, providing reliability and durability for mission-critical applications. For aerospace, marine, and engineering applications, Louis Metals’ SS 431 square bars/rods are trusted for dimensional accuracy, mechanical strength, and high resistance to wear and heat in harsh conditions.
Stainless Steel 431 Square Bars/Rods are martensitic stainless steels with significant constituent elements being Chromium (15–17%), Nickel (1.25–2.5%), and trace levels of Manganese, Silicon, Phosphorus, Sulfur, and Carbon. The alloy has high tensile strength of 850–1000 MPa, yield strength of around 520 MPa, and good ductility with elongation in the range of around 15%. It has a hardness of around 250 HB and has superior toughness and torque strength.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 431 | 0.20 | 17.00-15.00 | 1.00 | 2.50-1.25 | 0.040- | 0.030 | 1.00 |
| Element | Density | Electrical Resistivity | Modulus of Elasticity |
| SS 431 | 0.2800 lb/inch³ | 70° Ohms (circ mil./ft.) | 29.0 X 10^3 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 431 | 1.4057 | S43100 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
All these characteristics make SS 431 appropriate for use where high mechanical strength along with moderate corrosion resistance in mildly corrosive conditions is needed.
Stainless Steel 431 Square Bars and Rods are widely utilized where they must have high strength and moderate corrosion resistance. Some of their typical applications are in aerospace components, marine shafts, pump and valve components, fasteners, and automotive systems. Due to their hardness and toughness, they can be utilized to manufacture bolts, screws, and nuts for high stress applications. In the oil and gas sector, SS 431 bars are used in turbine blades, downhole equipment, and drilling tools. Due to their resistance to stress corrosion cracking, they can also be utilized to manufacture chemical processing equipment and components under high torque and impact conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Louis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
