Louis Metals is a renowned stainless steel manufacturer and supplier in Houston, USA, providing high-grade Stainless Steel 410 Square Bars and Rods to fulfill an array of industrial and commercial applications. Renowned for quality, reliability, and precision, Louis Metals produces these products under rigorous quality control standards to guarantee durability, dimensional accuracy, and uniform mechanical properties. Suppling customers throughout the United States and around the world, the business delivers on time and develops project-specific solutions for small, medium, or large projects. Louis Metals Stainless Steel 410 products are suited for applications where strength, resistance to corrosion, and good machinability are a requirement.
Stainless Steel 410 Square Bars and Rods are martensitic stainless steels with an approximate chromium content of 11.5–13.5% and possess good resistance to corrosion coupled with high strength and hardness. They offer a tensile strength of 700–950 MPa, yield strength of approximately 275 MPa, and elongation of about 20%. 410 stainless is magnetic in hardened and annealed conditions and may be heat treated to obtain higher mechanical strength. The square shape offers consistent strength along each side and has ease of machining and fabrication for precision parts and structural uses in industries.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50 mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 480 min | 275 min | 16 min | – | – |
| 204 | 1475 | 1005 | 11 | 400 | 30 |
| 316 | 1470 | 961 | 18 | 400 | 36 |
| 427 | 1340 | 920 | 18.5 | 405 | # |
| 538 | 985 | 730 | 16 | 321 | # |
| 593 | 870 | 675 | 20 | 255 | 39 |
| 650 | 300 | 270 | 29.5 | 225 | 80 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | 410S21 | – | – | 56A |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
410 Stainless Steel Square Bars and Rods find applications in a wide range of uses where wear resistance, strength, and moderate corrosion resistance are required. Some typical applications include pump parts, valves, fasteners, shafts, machine components, and tooling in automotive, aerospace, construction, and manufacturing industries. They also find application where heat treatment can be applied for further hardness, such as in industrial knives, dies, and cutting tools. Their squareness is especially advantageous for brackets, support structures, and framework, offering stability and convenience of assembly. Stainless Steel 410 is a cost-effective, versatile solution for engineering requirements of high performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
