Louis Metals is a Houston, USA-based prominent manufacturer and supplier of stainless steel items with high-performance Stainless Steel 347H Square Bars and Rods for heavy-duty applications in high-performance industries. These bars, renowned for their accuracy, strength, and reliability, are manufactured under strict quality control employing top-grade raw material and state-of-the-art processing methods. Louis Metals meets the global needs of clients with guaranteed delivery, technical service, and tailor-made solutions. Stainless Steel 347H products are particularly designed for corrosive and high-temperature environments and are a reliable option for fabricators and engineers in various power, petrochemical, and processing industries.
Stainless Steel 347H Square Bars and Rods are columbium-stabilized austenitic stainless steels with 17–19% chromium, 9–13% nickel, and columbium (niobium) for intergranular corrosion resistance. With a greater content of carbon (0.04–0.10%) compared to regular 347, 347H provides greater creep strength and superior performance at high temperatures. These bars have a tensile strength of approximately 485 MPa, a yield strength of 170 MPa, and an elongation of about 40%. The square cross-section provides equal strength and stability and is appropriate for structural use and components demanding close machining and thermal stability.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 347H | 0.04 – 0.10 | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 347H | 7.96 | 1450 ℃ | 515 | 205 | 40 | 201 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 347H | 1.4550 | S34709 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 347H Square Bars and Rods find extensive applications in industries requiring high temperature strength and corrosion resistance. Typical applications include heat exchangers, boiler fittings, pressure vessels, furnace components, and piping systems for oil refineries, chemical works, and power plants. The square shape also finds applications in frames, supports, and load-bearing structures where uniformity and stiffness are of the essence. 347H’s weld resistance to carbide precipitation qualifies it for fabricated assemblies subject to intense heat. It also finds application in exhaust systems, superheaters, and thermal process equipment where stability under thermal cycling is a must.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
