Louis Metals offers high-performance Forgings Aluminium 2014 in Houston, USA, catering to the aerospace, defense, and heavy machinery sectors. 2014 is a copper-bearing alloy with high strength and excellent machinability. Our forgings are designed for severe structural applications where mechanical performance is critical, providing reliability even at high-load and high-temperature applications.
Aluminium 2014 has copper (3.9–5%) as well as manganese and magnesium. It offers a tensile strength of 430–520 MPa in the T6 temper. The alloy is heat-treatable and possesses good toughness and fatigue strength but average corrosion resistance. It is excellent in machinability and responds favorably to forging, particularly when post-treatment is executed for strength.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Yes, Aluminum 2014 is suitable for high-temperature forging applications due to its excellent strength, thermal resistance, and good machinability, making it ideal for aerospace and automotive components.
Aluminum 2014 offers high strength, excellent machinability, good wear resistance, and superior performance under high-stress conditions, making it ideal for aerospace, automotive, and structural custom forgings.
Aluminium 2014 forgings find application in aircraft landing gears, heavy truck parts, aerospace structures, and weapon systems. Its strength is high and, therefore, finds application in automotive chassis, hydraulic components, and frames of high load. Though less corrosion resistant, it is best for indoor structural use or sheltered outdoor use where the main need is for strength.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
