Luois Metals stands out as a top manufacturer and supplier of high-quality Carbon Steel E-200 Bars, proudly based in Houston, USA. We focus on providing E-200 grade carbon steel bars that adhere to global standards for both performance and reliability. Our E-200 bars are recognized for their consistent mechanical strength and excellent machinability, making them ideal for a variety of industrial applications. Thanks to our advanced manufacturing techniques and rigorous quality control, Luois Metals guarantees precise dimensions and a superior finish in every product. We cater to industries across the U.S. and beyond, ensuring prompt delivery, competitive pricing, and personalized customer support.
Carbon Steel E-200 Bars are low carbon steel products that contain about 0.15–0.20% carbon, along with trace amounts of manganese, sulfur, and phosphorus. This specific composition allows for great machinability and moderate tensile strength, typically ranging from 370–470 MPa, with a yield strength of around 200 MPa. E-200 bars are known for their good surface quality, uniform hardness, and reliable dimensional tolerance. While they may not be the best choice for high-strength applications, they excel in machining and welding tasks. These bars can also be cold drawn for an improved finish and are often selected for manufacturing operations where moderate strength and high productivity are key.
| Specifications | : | ASTM A105, ASME SA105 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Carbon Steel EN Series Round Bars | : | 3.0 – 50.8 mm, Over 50.8 – 300mm |
| Carbon Steel EN Series Rectangular Bars | : | 6.35 x 12.7mm,6.35 x 25.4mm,12.7 x 25.4mm |
| Carbon Steel EN Series Hex Bars | : | AF5.8mm–17mm |
| Carbon Steel EN Series Square Bars | : | AF2mm – 14mm, AF6.35mm,9.5mm,12.7mm, 15.98mm,19.0mm, 25.4mm |
| Carbon Steel EN Series Flat Bars | : | 1/2” to 10” in thickness range of 2mm to 150mm, |
| Finish | : | Bright, Polish & Black |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | ||||||
| C% | Si% | Mn% | Cr% | Mo% | W% | |
| EN-1A | 0.007 TO 0.15 | 0.10 | 0.80 TO 1.00 | S | P | – |
| 0.20 TO 0.30 | 0.70 MAX | |||||
| EN-8 | 0.35 TO 0.45 | 0.05 TO 0.30 | 0.60 TO 1.00 | S | P | – |
| 0.06 MAX | 0.06 MAX | |||||
| EN-9 | 0.50 TO 0.60 | 0.05 TO 0.30 | 0.5 TO 0.80 | – | – | – |
| EN-19(V 320) | 0.35 TO 0.45 | 0.10 TO 0.30 | 0.5 TO 0.80 | 0.90 TO 1.40 | 0.20 TO 0.40 | |
| EN-24(V 130) | 0.35 TO 0.45 | 0.10 TO 0.35 | 0.45 TO 0.70 | 0.90 TO 1.40 | 0.20 TO 0.35 | NI |
| 1.3 TO 1.8 | ||||||
| EN-31 R-100 | 0.90 TO 1.20 | 0.10 TO 0.35 | 0.30 TO 0.75 | 1.00 TO 1.60 | – | – |
| EN-36C E-200 | 0.12 TO 0.18 | 0.10 TO 0.35 | 0.30 TO 0.60 | 0.60 TO 1.10 | – | NI |
| 3.0 TO 3.75 | ||||||
| EN-42 | 0.70 TO 0.85 | 0.10 TO 0.40 | 0.55 TO 0.75 | – | – | – |
| EN-44 | 0.90 TO 1.20 | 0.30 | 0.45 TO 0.70 | – | – | – |
| EN-45 F-110 | 50 TO 0.60 | 1.5 TO 2.0 | 0.70 TO 1.00 | – | – | – |
| EN-351 | 0.10 TO 0.20 | 0.35 | 0.60 TO 1.00 | 0.40 to 0.80 | 0.08 to 0.10 | NI |
| 0.60 TO 1.00 | ||||||
| EN-353 | 0.10 TO 0.20 | 0.35 | 0.50 TO 1.00 | 0.75 TO 1.25 | 0.08 to o.15 | NI |
| 1.00 TO 1.50 |
| Grade | HEAT TREATMENT | CORRESPONDING SPECIFICATION | |||||
| Hardening Temperature | Quenching Medium | Tempering Temperature | Brinell Rock well hardness | JAPAN JIS | AISI | POLDI THREAD | |
| EN-1A | – | – | – | – | – | – | – |
| EN-8 | 750-900 | OIL | 150-200 | ||||
| EN-9 | 850-900 | OIL | 200-250 | 55-60 | |||
| EN-19 (V 320) | 900-950 | OIL | 200-225 | 45-55 | SCM 4 | 4140 | |
| EN-24 (V 130) | 830-860 | OIL | 540-680 | 45-55 | SNCM 8 | 4340 | |
| EN-31 R-100 | 820-860 | OIL | 180-225 | 59-65 | |||
| EN-36C E-200 | 780-860 | OIL | 170-210 | 61-63 | SNC 22 | 3415 | |
| EN-42 | 600-700 | DIRECT HARDENING | 40-45 | ||||
| EN-44 | 650-750 | OIL | 150 | 45-50 | |||
| EN-45 | 830-860 | OIL | 470-520 | 50-55 | 9255 | ||
| EN-351 | 850-860 | OIL | 175-200 | 62-64 | |||
| EN-353 | 840-870 | OIL | 150-200 | 62-64 | |||
Common finishes for Carbon Steel E-200 Bar include hot rolled, cold rolled, polished, pickled, galvanized, and painted, each providing varying levels of surface smoothness, corrosion resistance, and appearance.
Yes, Carbon Steel E-200 Bar is available in various lengths. Suppliers typically offer customizable options, ranging from standard sizes to specific lengths according to customer requirements.
Carbon Steel E-200 Bar is commonly used in structural applications, manufacturing of automotive parts, machinery, tools, and general fabrication due to its strength, durability, and resistance to wear and corrosion.
Carbon Steel E-200 Bars find extensive use in industries that require dependable and easily machinable steel materials. They are frequently utilized in the production of fasteners, pins, hinges, brackets, and various general-purpose components. In the automotive industry, they are perfect for parts that don’t need high tensile strength but do require precision and durability. E-200 bars are also popular in furniture manufacturing, industrial machinery, and light construction frameworks. Their excellent surface finish and formability make them a great choice for turned parts and CNC-machined products.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
