Louis Metals is a leading stainless steel manufacturer and supplier located in Houston, USA. We take pride in offering high-performance Stainless Steel 316Ti Forgings, specifically designed for tough industrial settings. This titanium-stabilized austenitic stainless steel is renowned for its outstanding resistance to corrosion, oxidation, and high-temperature degradation. Perfect for components that face extreme heat and corrosive environments, our 316Ti forgings provide superior mechanical strength and long-lasting reliability. At Louis Metals, we create precision-engineered forgings that adhere to strict ASTM and ASME standards. Whether you need pressure vessels, flanges, or essential fittings, we have both custom and standard 316Ti forged solutions tailored to meet the rigorous demands of process-intensive industries.
Stainless Steel 316Ti Forgings are composed of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a small amount of titanium (at least five times the carbon content) to prevent carbide precipitation. With a carbon content of up to 0.08%, 316Ti offers improved strength at high temperatures. Its mechanical properties include a tensile strength ranging from 515–750 MPa, a yield strength of about 205 MPa, and a Brinell hardness between 150–200 HB. 316Ti excels in resisting corrosion in chloride and acidic environments and can endure prolonged heat exposure up to 900°C (1650°F) without losing its structural integrity.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Stainless Steel 316Ti Forgings are perfect for critical applications that involve high heat, pressure, and exposure to corrosive substances. They are commonly found in heat exchangers, pressure vessels, flanges, fittings, reactor components, and marine hardware. In industries like chemical processing, petrochemical, power generation, pulp & paper, and pharmaceuticals, 316Ti forgings are known for their reliability. The titanium stabilization not only enhances weldability but also provides excellent resistance to intergranular corrosion after welding or exposure to high temperatures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
