Louis Metals offers Stainless Steel 904L Rectangular Bars from high-quality, high-corrosion-resistant stainless steel. Having an alloy of chromium, nickel, copper, and molybdenum, Stainless Steel 904L is resistant to most acids and chemicals, such as sulfuric, phosphoric, and hydrochloric acids. These rectangular bars find perfect applications in chemical processing, pharmaceuticals, marine, and food processing sectors, where mechanical strength as well as corrosion resistance is required. Louis Metals takes care to produce each rectangular bar with accuracy and upholds the highest quality requirements for extraordinary performance in extreme applications.
Stainless Steel 904L Rectangular Bars consist of 25% chromium, 4.5% nickel, 1.5% copper, and trace elements including molybdenum that increase corrosion resistance. These bars possess high tensile strength (520–750 MPa) and yield strength (200–350 MPa) and provide very good resistance to pitting, crevice corrosion, and stress corrosion cracking. Stainless Steel 904L also provides better resistance to reducing and oxidizing acids. The rectangular shape makes them easy to machine and fabricate, and the bars possess very good mechanical properties at higher temperatures, thus suitable for severe duty in severe chemical conditions. Uses and Applications (100 Words):
| Standards | ASTM / ASME |
| Designation | B 649, SB 649 |
| Grade | 904L Rectangular Bars and Rods 904L Rectangular Bars and Rods: ASTM B 649, ASME SB 649 |
|
EN/DIN |
1.4539
X1NiCrMoCu25-20-5 |
|---|---|
|
AFNOR |
Z2CNDU25.20 |
|
UNS |
N08904 |
|
AISI |
904L / F904L |
|
BS |
904S13 |
|
SS |
2562 |
|
OTHER |
ASTM A182
ASTM A262
ASTM A479
ASTM B649 / ASME SB649
DIN 17440
EN10088-3
EN10272
NACE MR01-75 / ISO 15156
SEW 400-VdTÜV421 |
|
BRANDS |
URANUS B6™
VLX904™
AL-904L™
CRONIFER 1925™
2RK65™ |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Choose Stainless Steel 904L Rectangular Bars based on the specific corrosion resistance and strength requirements of your application. Consider factors such as temperature, chemical exposure, and mechanical stresses to ensure optimal performance.
Stainless Steel 904L Rectangular Bars are available in various sizes, typically ranging from 10mm to 100mm in thickness and widths up to 200mm, with customizable lengths. Specific dimensions can be tailored to meet project requirements based on customer needs.
Yes, Stainless Steel 904L Rectangular Bars can be used for underground applications due to their exceptional corrosion resistance, particularly in environments with high chloride content. Their durability ensures reliable performance in harsh, buried conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
