Luois Metals stands out as a top-notch manufacturer and supplier of Aluminium 6101 T6 bars and rods, proudly based in Houston, USA. We’re known for our unwavering dedication to quality and precision, offering high-performance aluminium products tailored for both electrical and structural uses. Our 6101 T6 bars and rods are crafted from premium-grade alloy using cutting-edge manufacturing techniques, guaranteeing outstanding conductivity, mechanical strength, and resistance to corrosion. With a variety of sizes and custom lengths available, Luois Metals is committed to providing dependable solutions with quick turnaround times, competitive pricing, and exceptional customer service throughout the United States and beyond.
The Aluminium 6101 T6 bars and rods are primarily made of aluminium, enhanced with magnesium and silicon, which creates a perfect blend of strength and conductivity. The T6 temper signifies that the alloy has undergone solution heat treatment and artificial aging, boosting its mechanical properties. Typically, this alloy boasts a tensile strength ranging from 190 to 240 MPa and impressive electrical conductivity (around 43% IACS). It also offers good corrosion resistance and weldability. These features make 6101 T6 an excellent choice for power transmission and structural components where both strength and electrical efficiency are crucial in challenging environments.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminum, Al | Magnesium, Mg | Silicon, Si |
|---|---|---|
| 98.9 | 0.60 | 0.50 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 97 MPa | 14069 psi |
| Yield strength | 76 MPa | 11023 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| INDIA | U.S.A. | BRITAIN | CANADA | GERMANY | RUSSIA | I.S.O. | FRENCH | NORTH AMERICA | DIN Nos. | |
|---|---|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) | (B.S.) | (DIN) | – | – | – | UNS | DIN | |
| 63401 | 91E | 6101 | 91E | D50S | E.Al.Mg.Si 0.5 | – | – | – | A96101 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6101 T6 bars are recyclable. Aluminium, including alloys like 6101 T6, can be recycled indefinitely without losing its properties, making it an environmentally friendly material for sustainable manufacturing.
Yes, Aluminium 6101 T6 rods can be customized in size and length to meet specific requirements. Manufacturers often offer various diameters, lengths, and finishes, allowing the rods to be tailored for different applications.
To select the right Aluminium 6101 T6 bar or rod, consider factors like strength requirements, electrical conductivity, corrosion resistance, weight, and intended application (e.g., electrical, structural, aerospace, or industrial use).
You’ll find Aluminium 6101 T6 bars and rods widely utilized across the electrical, power distribution, transportation, and construction sectors. They’re perfect for busbars, electrical connectors, power substations, and switchgear components thanks to their superb conductivity and moderate strength. In structural applications, they’re employed in overhead transmission lines, grounding bars, and mechanical supports where strength and conductivity need to work hand in hand. The alloy’s corrosion resistance and ease of fabrication make it a great fit for outdoor and industrial settings. With a solid balance of electrical and mechanical performance, it’s a reliable choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
