Luois Metals stands out as a reliable manufacturer and supplier of Super Duplex Steel Zeron 100 Bars and Rods right in Houston, USA. With a strong focus on quality and precision, Luois Metals provides high-performance bars and rods that are perfect for tough industrial applications. These products are crafted to meet international standards and undergo rigorous testing to ensure they are durable, corrosion-resistant, and strong. Thanks to their years of experience and a client-focused approach, Luois Metals has established itself as a dependable source for Super Duplex Steel solutions, catering to a variety of sectors including offshore, chemical processing, and marine industries across the USA and beyond.
Super Duplex Steel Zeron 100 Bars and Rods are primarily made up of chromium (25%), nickel (7%), and molybdenum (3.6%), with some copper and tungsten added in. This special blend gives them outstanding corrosion resistance, particularly in environments rich in chlorides. On the mechanical side, these bars and rods boast impressive strength, featuring a tensile strength of about 800 MPa and a yield strength of 550 MPa, along with good elongation and impact toughness. Their dual-phase microstructure enhances these mechanical properties, making them perfect for challenging service conditions where both high strength and corrosion resistance are crucial.
| Specifications | ASTM A276, A479, ASTM A182 / ASME SA276, SA479, SA182 |
|---|---|
| Grade | Super Duplex Steel UNS S32760 F55 |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Technique | uns S32760 Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Flat bar size | Thickness: 2 -100mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Processing | Bar cutting to 650mm |
| Certificates | EN 10204 / 3.1 |
| Condition | Hardened & tempered, annealed |
| Our uns S32750 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
| Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
|---|---|---|---|---|
| Zeron 100 | 109 | 80 | 25 | 28 HRC |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Zeron 100 | 1.4501 | S32760 |
Yes, Super Duplex Steel Zeron 100 bars can be welded. However, proper welding procedures and pre-heat treatments are essential to avoid issues like cracking and maintain its high strength and corrosion resistance.
Super Duplex Steel Zeron 100 rods are highly resistant to galvanic corrosion due to their exceptional corrosion resistance properties. However, if exposed to more active metals in a corrosive environment, some risk of galvanic corrosion may still exist.
Super Duplex Steel Zeron 100 rods are available in a range of diameters, typically from 10 mm to 300 mm, and can be customized based on specific requirements. They are commonly offered in finishes like hot-rolled, cold-rolled, and bright polished.
You’ll find Super Duplex Steel Zeron 100 Bars and Rods widely used in industries that require strong resistance to pitting, stress corrosion cracking, and general corrosion. They’re commonly found in offshore platforms, subsea equipment, chemical processing plants, and desalination systems. Additionally, they’re utilized in heat exchangers, pressure vessels, pumps, and valves where top-notch mechanical strength and corrosion resistance are essential. The blend of durability and cost-effectiveness makes these bars and rods a go-to choice for structural and engineering applications in aggressive environments, ensuring a long service life with minimal maintenance needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
