Louis Metals offers best–class Super Duplex Steel 2507 Bars and Rods in Houston, USA, for ultimate strength, corrosion resistance, and longevity. UNS S32750/S32760 (also referred to as 2507) is a super duplex stainless steel offering great mechanical properties with better corrosion resistance, particularly in chloride-rich and sea water conditions. Our ASTM A479 and ASTM A276 specification 2507 bars and rods are produced to order in special sizes and surface finishes. Louis Metals assists critical sectors such as offshore drilling, marine engineering, desalination, and chemical processing with reliable, high-performance super duplex bars designed for long life.
Super Duplex 2507 is comprised of about 25% chromium, 7% nickel, 4% molybdenum, and nitrogen, which increases the pitting and crevice corrosion resistance. It yields high tensile strength (~800–860 MPa) and yield strength (~550 MPa), with high resistance to fatigue and impact. The microstructure of the dual phase (ferrite and austenite) enhances structural integrity under stress and exhibits high resistance to chloride stress corrosion cracking. The material is strong at high temperatures and weldable under controlled conditions. Louis Metals maintains close dimensional tolerances and strict quality control in each bar and rod produced.
| Standards : | ASTM A276 / ASME SA276 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Super Duplex 2507 | 0.030 max | 1.20 max | 1.00 max | 0.035 max | 0.020 max | 24 – 26 | 3 – 5 | 6 – 8 | 0.24 – 0.32 | Balance |
| Grades | Density (g/cm 3) | Tensile Strength | Yield Strength (0.2%Offset) | Melting Point (°C) | Melting Point (°F) | Elongation |
| Super Duplex 2507 | 7.8 g/cm3 | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 1350 °C | 2460 °F | 15 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex 2507 | 1.4410 | S32750 |
Yes, Super Duplex Steel 2507 bars can be welded, but they require proper welding techniques and precautions to avoid issues like thermal distortion and cracking. It is recommended to use skilled welders and specific filler materials.
Super Duplex Steel 2507 bars provide excellent corrosion resistance, high strength, and resistance to pitting, crevice, and stress corrosion cracking, making them ideal for harsh environments.
Yes, Super Duplex Steel 2507 Bars can be used for underground applications due to their excellent corrosion resistance, high strength, and durability in harsh environments. They are suitable for piping, structural, and reinforcement applications in underground settings.
Super Duplex 2507 Bars and Rods are widely applied in offshore oil & gas platforms, heat exchangers, pressure vessels, subsea equipment, and desalination plants. High strength enables lightweight in structural applications, while increased corrosion resistance prolongs service life in hostile environments. The alloy is also utilized in chemical processing, pulp and paper bleaching, and pollution control systems. With superior performance in high-chloride and acid environments, Super Duplex 2507 offers credible solutions for challenging applications. Louis Metals provides customized diameters and lengths to address industry-specific engineering and operational needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
