Louis Metals is a well-established supplier and manufacturer of Alloy Steel F9 Bars and Rods in Houston, USA. We offer high–performance F9 bars suitable for exceptional performance in the high-temperature and high-pressure environment. Produced to high quality levels, our F9 rods achieve top mechanical strength, corrosion resistance, and longevity. Our F9 bars are extensively used in thermal power, oil refinery, and chemical processing plants. At Louis Metals, we bring together modern technology and metallurgical skill to guarantee that all F9 products are up to the challenging specifications of world-class engineering use.
Alloy Steel F9 Bars contain about 9% chromium and 1% molybdenum, in addition to carbon, manganese, and silicon. These constituents give greater strength, resistance to oxidation, and stability at high temperatures. The bars have a typical tensile strength of 620 MPa and yield strength of approximately 310 MPa. Creep resistance is improved by the increased content of molybdenum, while corrosion resistance in steam and oxidizing conditions is enhanced by chromium. F9 alloy bars also have good weldability and toughness, particularly following the proper heat treatment, and retain structural integrity following sustained exposure to high pressures and temperatures.
| Steel Round Bars type | F9 Round bars Die Steel Bar |
|---|---|
| Spring steel | 65Mn, 1566, 60Si2Mn, 9260, etc. |
| Standards | ASTM A689, JIS G4801, DIN 17221, GB/T 18254, ASTM A295, JIS G4805, etc. |
| Cold heading steel | ML25, ML35, etc. |
| Alloy structural steel | 40CrNiMo, SAE4330, 42CrMo, 15Cr2Ni2, 40CrNi2Mo, 35CrMoV,12Cr1MoV, ASTM4130, SCM420, 40CrV, etc. |
| Bearing steel | GCr15, SAE52100, GCr15SiMn, 100CrMnSi6-4, SJU2, etc. |
| Available Material Grade | 42CrMo4/SCM440/AISI 4140/DIN 1.7225, 4130 / 1.7218, 4140 / 1.7225, 4340 / 1.6582, 5140 / 1.7035, 8620 / 1.6523, EN19 / EN24H13 alloy steel round bar, 42 Crmo4 Alloy Steel Round Bar, AISI 4140 alloy steel round bar , 42CrMo4 alloy steel rods
|
| Military steel | 20Cr2Ni4A, 18Cr2Ni4WA, 23CrNiMo7-4-7, etc. |
| F9 Round bars Diameter | 5mm-500mm (Customized size is acceptable) |
| F9 Round bars Length | 1m-9m or according to the customer’s requirement. |
| F9 Round bars Range | Range – 3.17mm to 350mm dia |
| F9 Round bars Technique | Forged/Hot Rolled/Cold Drawn/Peeled |
| F9 Round bars Surface | bright round bar, pickled round bar, black round bar |
| F9 Round bars Type | Round bar, rod, square bar, flat bar, hexagon bar, angle bar, channel bar, threaded bar |
| Package Details | Standard seaworthy package(wooden boxes package, pvc package, or other package) |
| Other processing service | Hot dipped Galvanized, pre-galvanized, Color painting,coated, cutting, bending,punching |
| Test Certificate | Mill Test Certificate as per EN 10204 / 3.1B |
| Grade | C | Mn | Si | P | S | Cr | Mo |
| Alloy Steel F9 | 0.15 max | 0.3-0.6 | 0.5-1 | 0.03 | 0.03 | 8-10 | 0.9-1.1 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 380 | 585 | 20 % |
|
SHAPE |
POUNDS PER FOOT |
|---|---|
|
Round |
D2 x 2.67 |
|
Hexagon |
D2 x 2.945 |
|
Square |
D2 x 3.4 |
|
Flat |
Thickness (in.) x Width (in.) x 3.4 |
Alloy Steel F9 Bars and Rods are mainly used in high-temperature applications like steam turbines, aerospace components, and power plants due to their strength and heat resistance.
Alloy Steel F9 offers excellent creep strength, high tensile strength, and resistance to thermal fatigue, making it ideal for high-pressure environments.
Alloy Steel F9 Bars and Rods can be used in high-temperature and high-pressure applications, especially in the petrochemical and power generation industries. They are used typically in pressure vessels, steam boilers, turbine parts, superheaters, and heat exchangers. They are also used in the fabrication of refineries and thermal power plants where thermal and chemical stress resistance is essential. F9 alloy steel rods provide outstanding performance under conditions of varying temperatures and harsh fluids and are thus a dependable option for prolonged service in critical process equipment and infrastructure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
