Louis Metals supplies premium-performance Nitronic 60 bars and rods from Houston, USA. Austenitic stainless steel Nitronic 60 is engineered for harsh environments and offers superior corrosion resistance, wear resistance, and galling resistance. Our inventory meets ASTM standards and is precision-machined for applications where reliability and durability are critical.
Nitronic 60 combines chromium, nickel, silicon, and manganese to deliver corrosion resistance comparable to 304/316 stainless steel while offering roughly twice the yield strength. In annealed form, tensile strength typically reaches ~655–724 MPa, with yield strength of ~345–379 MPa. It retains ductility (~35% elongation) and toughness across a wide temperature range, and maintains stability even under heavy wear
AK Steel
| Standards : | UNS S21906 | AMS 5656 | MIL-T-9821 | ASTM A276 | ASME SA276 UNS S21800 | Alloy 218 | ASME SA 193 | AMS 5848 | ASTM A 193 EN 1.3964 | ISO 15156-3 | NACE MR0175 | UNS S20910 | AMS 5764 | ASTM A193 | Werkstoff 1.3964 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | Si | S | Cr | Ni |
| Nitronic 50 | 0.06 max | 0.10 max | 0.1 max | 23.50 | 14.00 – 17.00 | 13.50 max |
| Nitronic 60 | 0.10 max | 9.00 max | 4.5 max | – | 18.00 | 9.00 max |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness |
| Nitronic 50 | 95 | 50 | 35 % | 241 |
| Nitronic 60 | 105 | 55 | 35 % | – |
| STANDARD | UNS | EN | ISO | NACE | AMS | ASTM | Werkstoff | other |
| Nitronic 40 | S21906 | – | – | – | 5656 | A276 | – | MIL-T-9821 |
| Nitronic 50 | S20910 | 1.3964 | 15156-3 | MR0175 | 5656 | A193 | 1.3964 | MIL-T-9821 |
| Nitronic 60 | S21800 | – | – | – | 5848 | A193 | 1.3964 | Alloy 218 |
Yes, Nitronic bars, such as Nitronic 50 and Nitronic 60, can be welded using standard welding techniques, including TIG, MIG, and shielded metal arc welding (SMAW), with appropriate filler material.
Suitable welding processes for Nitronic bars include TIG (Tungsten Inert Gas), MIG (Metal Inert Gas), and stick welding, with proper filler materials to ensure strong, corrosion-resistant joints.
Nitronic rods are available in a range of sizes, typically from 1/8" to 12" in diameter. Common finishes include hot-rolled, cold-rolled, polished, and machined, depending on the application.
Nitronic 60 bars and rods are used extensively in valve stems, pump shafts, fasteners, bearing races, and expansion joints. Due to their high resistance to galling and wear, they are the best suited for bridge pins, marine shafts, and sliding parts in industrial equipment. Since it resists corrosion as well as mechanical wear, Nitronic 60 increases life in tough environments HP Alloy.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Louis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
