Luois Metals is a well-respected manufacturer and supplier of Nickel Alloy 201 Forgings, proudly based in Houston, USA. We focus on providing high-performance, corrosion-resistant forged components that are built to tackle the toughest industrial challenges. Our Nickel Alloy 201 Forgings are crafted with precision, utilizing top-quality materials and cutting-edge forging techniques to ensure they deliver strength, reliability, and a long lifespan. With expert technical support and a strong commitment to quality, Luois Metals caters to clients in the chemical, marine, aerospace, and energy sectors. Plus, we offer quick delivery, custom sizing, and competitive pricing, making us your go-to source for Nickel Alloy 201 Forgings in the USA.
Nickel Alloy 201 Forgings are made up of 99.6% pure nickel, along with small amounts of elements like iron, carbon, and copper. This unique composition gives them outstanding corrosion resistance, particularly in alkaline and reducing environments. On the mechanical side, Alloy 201 boasts good tensile strength, low hardness, and excellent ductility, which makes it perfect for forming and welding. Its low carbon content helps prevent embrittlement at high temperatures. These forgings maintain their mechanical properties in both high and low-temperature settings, making them reliable for critical operations that require purity, strength, and stability under thermal and chemical stress.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | BS 3072, BS 3073, BS 3074, BS 3075, BS 3076, NA11 DIN 17740, 17750, 17751, 17752, 17753, 17754, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Yes, Nickel Alloy 201 can be forged into custom shapes. Its excellent ductility and malleability make it ideal for creating tailored components to meet specific design and application requirements.
Post-forging operations for Nickel Alloy 201 typically include heat treatment to enhance mechanical properties, machining for precision shaping, and surface finishing to ensure corrosion resistance and optimal performance.
To determine if Nickel Alloy 201 forgings meet your needs, evaluate their chemical composition, mechanical properties, and corrosion resistance against your application requirements. Consulting with experts or suppliers can ensure the material's suitability.
Nickel Alloy 201 Forgings find their place in industries where high corrosion resistance, especially against caustic alkalis, is crucial. In the chemical processing sector, they’re perfect for components like reactors, heat exchangers, and vessels that come into contact with harsh chemicals. In electronics, their high purity and low gas content make them ideal for battery components and semiconductor manufacturing. The marine and offshore industries also rely on them for hardware and equipment that face saltwater exposure. Additionally, they’re utilized in food processing and synthetic fiber production, showcasing their versatility across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
