Luois Metals is a reliable manufacturer and supplier of Nickel Alloy 200 Forgings, proudly serving various industries throughout Houston, USA. We focus on providing top-notch forged components crafted from commercially pure nickel, celebrated for their outstanding corrosion resistance and mechanical performance. With our state-of-the-art manufacturing capabilities and rigorous quality control, our Nickel Alloy 200 Forgings are perfect for even the most demanding industrial settings. At Luois Metals, we offer custom sizes, quick delivery, and competitive pricing, making us the go-to source for dependable nickel forgings used in chemical processing, marine, aerospace, and other high-performance engineering applications across the United States.
Nickel Alloy 200 Forgings find extensive use in industries that demand superior resistance to corrosive chemicals and high thermal conductivity. In the chemical and petrochemical sectors, they are utilized for components like valves, pump parts, and pressure vessels that come into contact with caustic solutions and acids. The electronics industry relies on this alloy for battery components, terminals, and electrical connectors due to its purity and conductivity. Additionally, the marine and aerospace industries apply it in parts that need to withstand saltwater and stress corrosion.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | BS 3072, BS 3073, BS 3074, BS 3075, BS 3076, NA11 DIN 17740, 17750, 17751, 17752, 17753, 17754, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
After forging Nickel Alloy 200, controlled cooling methods such as air cooling or furnace cooling are typically used to avoid rapid temperature changes and prevent distortion. Gradual cooling helps maintain the material's mechanical properties and prevent cracking.
Post-forging operations for Nickel Alloy 200 include annealing to relieve internal stresses and improve ductility, followed by machining or surface finishing to achieve precise dimensions and surface quality. These processes ensure the alloy's optimal performance and structural integrity.
The ideal temperature range for forging Nickel Alloy 200 is between 1,900°F (1,038°C) and 2,100°F (1,149°C). This range ensures proper malleability and helps achieve the desired mechanical properties during the forging process.
Nickel Alloy 200 Forging is widely utilized in applications for high corrosion strength. It contains chemical processing equipment, reactors and piping systems as well as Aerospace components, Electrical systems and Marine environments. They are also utilized in the food and beverage industry for equipment like storage tanks, heat exchangers and valves. The alloy’s excellent weldability and formability make it ideal for applications exposed to extreme temperatures and harsh chemical environments, ensuring long-term durability and reliability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
