Luois Metals stands out as a top-notch manufacturer and supplier of Nickel Alloy 201 Bars and Rods, proudly rooted in Houston, USA. We focus on creating high-purity, corrosion-resistant nickel products that are specifically designed for critical industrial applications. Our Nickel Alloy 201 Bars and Rods are meticulously crafted to meet international quality standards, ensuring they deliver outstanding performance in both chemical and thermal environments. With a reputation for timely deliveries, tailored solutions, and competitive pricing, Luois Metals caters to a variety of sectors, including electronics, chemical processing, aerospace, and marine industries. Our unwavering commitment to quality and customer satisfaction makes us your go-to source for Nickel Alloy 201 Bars and Rods.
These Nickel Alloy 201 Bars and Rods are made up of 99.6% pure nickel, featuring minimal carbon content along with trace elements like iron and copper. This alloy is known for its remarkable resistance to alkaline solutions, impressive ductility, and solid mechanical strength. The low carbon content helps to prevent embrittlement at high temperatures, making it a great choice for applications that require heat resistance. Alloy 201 consistently showcases reliable mechanical properties, including moderate tensile strength, excellent formability, and good weldability. These bars and rods perform well across a broad temperature range, making them perfect for environments that demand chemical stability, purity, and resistance to corrosion and oxidation.
| Grade | Nickel 201 |
|---|---|
| Specification | UNS N02201, ASME SB160/ASTM B160 |
| Round bar size | Dia: 3mm~800mm |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4mm to 100mm |
| Hex Bar size | 2mm to 100mm A/F |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75mm section; 5 to 6mm thickness |
| Flat bar size | Thickness: 2mm to 100mm |
| Width: 10mm to 500mm | |
| Hollow Bar | 32mm Outside Diameter x 16mm Inside Diameter to 250mm Outside Diameter x 200mm Inside Diameter) |
| Angle bar size | 3*20*20~12*100*100 |
| Form | Rings, Hollow, Flat Bar, Rectangle, Triangle, Square,Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Round, Channel Bar, Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Tolerance | H8, K12, H10, H11, K10, H9, K11, K9, H12, H13, or custom |
| Technique | Forged Round Bar, Rod, Hot Rolled, Cold Drawn, Cold Rolled, |
| Condition | annealed, Hardened and tempered |
| Surface | Polished, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Bright, Hairline |
|
Grade |
Fe |
Si |
C |
S |
Ni |
Mn |
Mg |
Cu |
Ti |
|---|---|---|---|---|---|---|---|---|---|
|
Nickel 201 |
0.4 max |
0.2 max |
0.02 max |
0.01 max |
99.0 min |
0.35 max |
0.15 max |
0.25 max |
0.1 max |
|
Density |
Elongation |
Tensile Strength |
Melting Point |
Yield Strength (0.2%Offset) |
|---|---|---|---|---|
|
8.9 g/cm3 |
45 % |
Psi – 67000 , MPa – 462 |
1446 °C (2635 °F) |
Psi – 21500 , MPa – 148 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
AFNOR |
GOST |
BS |
JIS |
EN |
|---|---|---|---|---|---|---|---|
|
Nickel 201 |
N02201 |
2.4068 |
– |
НП-2 |
NA 12 |
NW 2201 |
NLC-Ni 99 |
Type | SIZES (Inches) | ISO Tolerance | SIZES (mm) |
|---|---|---|---|
Peeled and Polished | 1.50″ to 6.00″ | h11-DIN 1013 | 40.00 to 150.00 |
Cold Drawn and Ground | 5/6″ to 2.50″ | h9-h8-h11-h10 | 10.00 to 75.00 |
Cold Drawn and Polish | 1/8″ to 3.00″ | h9-h8-h11-h10 | 3.00 to 75.00 |
Peeled and Ground | 3/4″ to 2.00″ | h10-h9-h11 | 20.00 to 50.00 |
Cut to size on request (tolerance +2/-0 mm).
50.0 | 6.0 |
45.0 | 5.0 |
60.0 | 8.0 |
55.0 | 7.0 |
70.0 | 10.0 |
65.0 | 9.0 |
75.0 | 12.0 |
90.0 | 20.0 |
80.0 | 16.0 |
100.0 | 25.0 |
160.0 | 35.0 |
130.0 | 30.0 |
200.0 | 40.0 |
Yes, Nickel Alloy 201 rods can be welded using various welding techniques, including TIG and MIG welding.
Nickel Alloy 201 bars exhibit excellent corrosion resistance, high thermal conductivity, good mechanical properties, and outstanding weldability, especially in reducing environments.
Nickel Alloy 201 rods are available in various sizes, typically ranging from 1/8" to 3" in diameter, and come in finishes such as bright, polished, and cold drawn.
Nickel Alloy 201 Bars and Rods find extensive use in industries where high chemical resistance and thermal stability are crucial. In the chemical processing sector, they are utilized for crafting caustic handling equipment, reactors, and storage tanks. The electronics industry appreciates their high purity for battery components and semiconductor manufacturing. In aerospace and marine applications, they are used in hardware and components that face corrosive environments. Additionally, they play a role in food processing, synthetic fiber production, and heat exchangers.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
