Luois Metals is your go-to manufacturer and supplier of top-notch Copper Nickel Rectangular Bars, proudly based in Houston, USA. With years of experience under our belt in the metal industry, we’ve built a strong reputation for providing corrosion-resistant, durable, and precisely crafted copper nickel products. Our Copper Nickel Rectangular Bars come in a variety of sizes and specifications, ensuring we meet both domestic and international standards. We’re known for our unwavering commitment to quality and timely delivery, serving industries like marine, chemical processing, oil and gas, and power generation. When it comes to premium copper nickel solutions across the U.S., Luois Metals is a name you can trust.
These Copper Nickel Rectangular Bars typically feature compositions of 90/10 (90% copper, 10% nickel) or 70/30 (70% copper, 30% nickel), which provide outstanding resistance to corrosion, particularly in seawater. To boost strength and corrosion resistance, these alloys often have small amounts of iron and manganese added. They boast impressive mechanical properties, including high tensile strength (up to 500 MPa), excellent ductility, and superior thermal conductivity. The bars maintain their properties across a wide temperature range and offer exceptional weldability and workability, making them perfect for demanding engineering and marine applications.
| Standard | ASTM B111, ASME SB111 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000 PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000 PSi |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed / pickled |
| CG | Centreless ground | HF | Hot finished |
| ST | Smooth turned | PR | Peeled / reeled |
| CD | Cold drawn | P | Polished |
| P&T | Peeled / turned | RT | Rough turned and peeled |
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
Yes, Copper Nickel Rectangular Bars are customizable in terms of size, thickness, length, and alloy composition to meet specific requirements for various applications. Customization ensures optimal performance in marine, chemical, and industrial environments.
You’ll find Copper Nickel Rectangular Bars widely used in industries where strength, corrosion resistance, and thermal conductivity are essential. Common applications include seawater piping systems, heat exchangers, condenser tubes, marine hardware, shipbuilding components, and desalination plants. They’re also utilized in offshore oil rigs, chemical processing facilities, and power generation equipment. Thanks to their anti-fouling and biofouling resistance, these bars are especially suited for marine and underwater applications. Plus, their durability and ease of fabrication make them an excellent choice for heavy-duty structural components in tough environments. Luois Metals is here to provide customized bars tailored to your needs!
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
